Kilogram-scale preparation for each batch

High alloying degree, close to the oretical value.

Uniform size of PtRu nanoparticles

with the standard difference of ±0.3 nm.

DMFC (Direct Methanol Fuel Cell)

Anodic CO-tolerant catalyst for PEMFC (Proton Exchange Membrane Fuel Cell)

Cathode catalyst for AEMWE (Alkaline Anion Exchange Membrane Water Electrolyzer)

Anode catalyst for AEMFC (Alkaline Anion Exchange Membrane Fuel Cell)

PtRu Alloy Supported on Carbon

Catalysts	Specifications	Compositions	Average Particle Size(nm)	Electrochemical Active Area (ECSA m²/g)	Mass Activity(MA, mA/mg)	Specific Surface Area(m²/g)
Pt/C	HiCaP40	40wt.%Pt,60wt.%C	2.8	95	130	140
	HiCaP50	50wt.%Pt,50wt.%C	3.3	85	130	110
	HiCaP60	60wt.%Pt,40wt.%C	3.3	90	135	296
	HiCaP70	70wt.%Pt,30wt.%C	3.3	55	134	85
PtCo	HiCaPC50	50wt.%Pt,40wt.%C	5.2	65	350	110
Pt Black	HiCaP100	>95wt.%Pt	5.0	≥32	80	35
Ir-Black	HiCal100	>95wt.%lr	4.5	120	180	52
Ir02	HiCalO100	~80 wt.%lr	7.0	30	240	120
Low-lr Catalyst	HiCal070	~56wt.%lr	4.5	60	180	75
lr/C	HiCal20	20wt.%Ir,80wt.%C	2.5	180	600	500
lr/C	HiCal85	85wt.%lr,15wt.%C	4.5	85	190	145
PtRu Black	HiCaPR100	65wt.%Pt,35wt.%Ru	3.2	30	190	40
PtRu/C	HiCaPR60	40wt.%Pt,20wt.%Ru,40wt.%C	4.0	85	1	100
Ru-Black	HiCaR100	>95wt.%Ru	7.0	40	200	80

Diagram:
